Coax cable ?
- Thread starter Chipmunk
- Start date
Lots of brands out there rated for direct burial. Myself, I've been using DXEngineering coax for about 5 years now with zero issues. Don't know (or care) who makes it for them, but it's quality stuff, IMO.
7 3
7 3
JEFA tech is one many have recommended and what I will buy next as the reviews are excellent. Nice prices too. The DXE stuff is good stuff too, I have a few jumpers of them with dxe pl-259's. Pricey but good stuff.
This is buried in my yard for the last 2 years. Running up to 1.2kw through it on all bands from 17 to 10 feeding my IMAX 2000.
Any coax. Just put it into blue water pipe.
Mike
Mike
Best post in the thread. Just seal the sections with good glue.
- 399
Unless the pipe has a constant dried air purge air flow, it eventually will fill with water from condensed moisture in the air. For this reason you still need direct bury rated coax when running it in buried pipes.
Not so.Condensation will still allow moisture into the pipe I believe.Humidity is a beast here in Florida and it does.
Yup. Been th
Been there,done that. I buried several lengths of cable inside 3 inch pvc pipe and it eventually filled with water from condensation. I drilled a small weeping hole in the low end and never had the problem again. I have had a few commercial installations too that had buried cables in a conduit that were capped off and they filled with water as well. It comes from condensation as the warm humid air gets cooled underground. 100% guaranteed to fill with water eventually if both ends are sealed off and no weep hole is drilled.
Excerpt
:
There is a way to avoid all the water problems and guarantee your installation will last even if the water does get into the conduit. Whenever you are laying conduit underground always use gel-filled direct burial type cables and wires with every installation. Any “Wet Rated” cable or wire can be used to eliminate the problem completely. Then when the water does get in, it won’t matter at all. Use the conduit for running cable but do not rely on it to keep your cables and wires dry. Unlike direct burial the conduit will allow you to pull in other cables later and the water proof cables will insure that your installation will last a lifetime.
from
73
Jeff
:
There is a way to avoid all the water problems and guarantee your installation will last even if the water does get into the conduit. Whenever you are laying conduit underground always use gel-filled direct burial type cables and wires with every installation. Any “Wet Rated” cable or wire can be used to eliminate the problem completely. Then when the water does get in, it won’t matter at all. Use the conduit for running cable but do not rely on it to keep your cables and wires dry. Unlike direct burial the conduit will allow you to pull in other cables later and the water proof cables will insure that your installation will last a lifetime.
from
HOW TO GET THE WATER IN YOUR CONDUIT OUT - FM Systems
HOW TO GET THE WATER IN YOUR CONDUIT OUT By: Don McClatchie Many CCTV installations require metal or plastic electrical conduit to be used to protect the cables and wires from wear and tear or tampering. Whether the conduit is above ground outside […]
www.fmsystems-inc.com
73
Jeff
Excerpt
:
There is a way to avoid all the water problems and guarantee your installation will last even if the water does get into the conduit. Whenever you are laying conduit underground always use gel-filled direct burial type cables and wires with every installation. Any “Wet Rated” cable or wire can be used to eliminate the problem completely. Then when the water does get in, it won’t matter at all. Use the conduit for running cable but do not rely on it to keep your cables and wires dry. Unlike direct burial the conduit will allow you to pull in other cables later and the water proof cables will insure that your installation will last a lifetime.
from
HOW TO GET THE WATER IN YOUR CONDUIT OUT - FM Systems
HOW TO GET THE WATER IN YOUR CONDUIT OUT By: Don McClatchie Many CCTV installations require metal or plastic electrical conduit to be used to protect the cables and wires from wear and tear or tampering. Whether the conduit is above ground outside […]www.fmsystems-inc.com
73
Jeff
Good idea but that gel-filled cable comes with a premium price.......usually. Most direct burial type cables simply have a non-contaminating outer jacket without the gel.
Agree Capitan, just info that it will fill with water.
We ran thousands of feet of cable and wire at the processing plant through underground conduit for both power and control circuits.
Water would always find it's way in, especially in that environment with process equipment that had to be sanitized daily.
Direct bury coax is the way to go.
73
Jeff
We ran thousands of feet of cable and wire at the processing plant through underground conduit for both power and control circuits.
Water would always find it's way in, especially in that environment with process equipment that had to be sanitized daily.
Direct bury coax is the way to go.
73
Jeff
