Turner ssk to a Icom 746.


Greg T

945 (Jazz Singer) Upper Peninsula of Michigan
Sep 18, 2014
648
890
103
68
Escanaba, Michigan
ICOM-IC7400-IC746-IC746PRO-IC756PRO-IC7700-IC7800 (see HM-36 below )
PIN1 MIC + DC VOLTS FOR ICOM ONLY MICROPHONE
PIN2 + 8VOLTS 10Ma TO AVOID DAMAGING THE REGULATOR DO NOT
SHORT TO GROUND
PIN3 UP/DOWN
PIN4 SQUELCH
PIN5 PTT
PIN6 GROUND
PIN7 MIC SCREEN/EARTH
PIN8 AUDIO OUT


SSK:
Shield ----- audio grnd
White ------audio
Red ---------PTT
Blk ----------PTT Grnd

  • Like
Reactions: Woody-202

Greg T

945 (Jazz Singer) Upper Peninsula of Michigan
Sep 18, 2014
648
890
103
68
Escanaba, Michigan
If you're still around to see this, it looks like this for your rig:
(SSK colors)
5 - Red
6 - Black
7 - Shield
8 - White
** You may need to jump across 6 and 7**
