Ranger (RCI) Ranger (Texas Ranger) TR-396FC

Added by BJ radionut
Create date May 5, 2022

Overview Gallery

Write a review Ask a question

Ranger / RCI Models

TR-396FC

RADIO MODIFICATIONS

Switch Frequency Conversion (P5 P6)
Channel Chart After Modification

Mic Wiring

Stock
1- Shield (Ground)
2- Yellow (Audio)
3- Red (Transmit)
4- White (Receive)
Astatic (4 wire)
1- Shield
2- White
3- Red
4- Black
Astatic (6 wire)
1- Shield & Blue
2- White
3- Red
4- Black
Yellow NC
Daiwa EM-500
Cobra CA Series
1- Shield & Black
2- Red
3- White
4- Blue
Galaxy DC-521S (4 wire)
1- Shield
2- Yellow
3- Red
4- Black
Galaxy CB-660EI
1- Shield & Black
2- White
3- Red
4- Blue
Sadelta
1- Shield
2- White
3- Brown
4- Green
Turner
1- Shield & Red
2- White
3- Blue
4- Black
Yellow NC
