Amplifier purchase help

Discussion in 'Amplifiers' started by BammBamm, Nov 26, 2018.

  1. BammBamm

    BammBamm Instigators ...173 on the southside.

    Joined:
    May 24, 2010
    Messages:
    575
    Likes Received:
    163
    I have been looking at buying a new/bigger amp but other than rm Italy and copper electronics where can I buy a new one from? I’m looking for somewhere around 500 Watts and must have SSB. I tried to look at Xforce but no amps come up? I liked the midnight special line but like I said it seems to be gone.




  2. rabbiporkchop

    rabbiporkchop Well-Known Member

    Joined:
    Jan 18, 2007
    Messages:
    1,646
    Likes Received:
    495
    What's wrong with Texas Star amps?

  3. kopcicle

    kopcicle Sr. Member

    Joined:
    Feb 17, 2016
    Messages:
    635
    Likes Received:
    621
    What isn't wrong with Texas Star amplifiers ?

    357magnum and rabbiporkchop like this.
  4. rabbiporkchop

    rabbiporkchop Well-Known Member

    Joined:
    Jan 18, 2007
    Messages:
    1,646
    Likes Received:
    495
    Compared to most of the junk out there, they can work fine, assuming no voltage drop and not overdriven.
    Not many options for thermal tracking.

  5. Handy Andy

    Handy Andy Do Your Research First, Then Decide...

    Joined:
    Apr 23, 2018
    Messages:
    1,585
    Likes Received:
    1,305

    In placing the above response thru a self-aware analysis recursive algorithm...

    I can't think of any type or kind of response that is better than that!

    LOL!

    357magnum likes this.
  6. Handy Andy

    Handy Andy Do Your Research First, Then Decide...

    Joined:
    Apr 23, 2018
    Messages:
    1,585
    Likes Received:
    1,305
    @BammBamm - Use what works for you.

    The T/S 500 although more Class C than AB biasing - is a better quality unit than the 203 - but it is also made up of Bi-polar devices. Compared that to the 203 - it has none - it is all MOSFET.

    TS has more brute force and direct approach to linear operation - so the components are discrete and can be changed to adapt to the environment it will be used in. Versus the Surface mounting that is a little less user friendly when it comes to repairs or field-level adjustments - requires more attention to the input dynamics of the radios' own output.

    T/S 500 would work better for High Drive - (HD reference here) radios - so SSB types with more PEP capabilities like what the 980's SSB mode uses - will make the Amp work for you and perhaps sound better than the MOSFET ones that are more Gate Bias driven which really depends upon the users' friendliness to the requirements the Amp needs to work linearly - not like an FM station (pinching audio) - too much drive into a MOSFET amp and she's done (READ:TOAST) just like the others that use amplified inputs to obtain non-linear output of the output finals.

  7. BlowinSmoke

    BlowinSmoke Member

    Joined:
    Jun 3, 2017
    Messages:
    45
    Likes Received:
    9
    What is your budget? Can you stand to have 900 watts PEP for SSB? Can make some suggestions but would like to keep within your budget.

  8. Low_Boy

    Low_Boy Well-Known Member

    Joined:
    Jan 21, 2010
    Messages:
    735
    Likes Received:
    215
    Fore base use? AL811 or AL811H.

  9. kopcicle

    kopcicle Sr. Member

    Joined:
    Feb 17, 2016
    Messages:
    635
    Likes Received:
    621
    And don't expect 800 watts out of it :)

    rabbiporkchop likes this.
  10. oldtymer

    oldtymer Member

    Joined:
    Nov 15, 2018
    Messages:
    32
    Likes Received:
    39
    On 10 &11 450 is about average output. Try & overdrive it for more & you will be buying a lot of tubes.

    kopcicle likes this.
  11. 338_MtRushmore

    338_MtRushmore Well-Known Member

    Joined:
    Jun 17, 2012
    Messages:
    828
    Likes Received:
    330
    Is this referring to the H? If so, what will the 3 tubes do?

  12. oldtymer

    oldtymer Member

    Joined:
    Nov 15, 2018
    Messages:
    32
    Likes Received:
    39
    The 3 holer-the H will do a bit more, the extra tube won't matter much.
    On 20,40, & 75 you will see 600 for the 3 Tube & 750-800 foe the H.
    On the receiving end it is only a db, not really a difference.
    For what you pay for a new 811 today you can get a used AL-80B with a 3-500z
    that you can drive the snot out of it with your dual final radios & get better output &
    not strain the tube.
