cobra 148gtl stock mic

Discussion in 'General CB Services Discussion' started by kaos513, Mar 14, 2019.

  1. kaos513

    kaos513 Well-Known Member

    Joined:
    Apr 10, 2014
    Messages:
    1,841
    Likes Received:
    448
    I have a cobra coffin stock mic 5 pin colors are white,shield,yellow,red and purple when i hook it up squeals like a pig any one know right color code to wire it to 5 pin cobra 148 gtl? thanks.




  2. Handy Andy

    Handy Andy Do Your Research First, Then Decide...

    Joined:
    Apr 23, 2018
    Messages:
    2,068
    Likes Received:
    1,852
    You have open up the coffin and look inside...
    [​IMG]

    Well maybe not like that...

    More like you'll have to open up the Mic handset and review the wiring to make sure you have it wired correctly.

    The DPDT switch inside is a dual pole for RX/TX and Audio SEPARATE - and AUDIO SHIELD has and offers it's own ground.

    undertaker, Redbeard U812 and psycho like this.
  3. Redbeard U812

    Redbeard U812 Sr. Member

    Joined:
    Jul 14, 2018
    Messages:
    912
    Likes Received:
    1,010
    Maybre dis helps


    Attached Files:

  4. Crossbow

    Crossbow Active Member

    Joined:
    Mar 25, 2016
    Messages:
    145
    Likes Received:
    72
    Cobra stock mic I have is wired like this:
    1. Yellow
    2. Shield
    3. Black
    4. Purple
    5. Red

    kaos513 likes this.
  5. kaos513

    kaos513 Well-Known Member

    Joined:
    Apr 10, 2014
    Messages:
    1,841
    Likes Received:
    448
    Works perfect

    357magnum, Crossbow and S&W357 like this.
