Unbuilt Heathkit SB-1000

Discussion in 'Amplifiers' started by Mudfoot, Sep 7, 2019.

  1. Mudfoot

    Mudfoot Sr. Member

    Joined:
    Jun 17, 2009
    Messages:
    9,442
    Likes Received:
    4,025
    Tallman likes this.

  2. BJ radionut

    BJ radionut Supporting Member and 6m addict

    Joined:
    May 9, 2008
    Messages:
    2,450
    Likes Received:
    1,871
    ????:confused:

    Marconi likes this.
  3. Captain Kilowatt

    Captain Kilowatt Professional Amateur
    Staff Member

    Joined:
    Apr 6, 2005
    Messages:
    15,785
    Likes Received:
    8,167
    [​IMG]

  4. KD2GOE

    KD2GOE W9WDX Amateur Radio Club Member

    Joined:
    May 30, 2013
    Messages:
    896
    Likes Received:
    158
  5. BJ radionut

    BJ radionut Supporting Member and 6m addict

    Joined:
    May 9, 2008
    Messages:
    2,450
    Likes Received:
    1,871
    Ridiculous Cost! When you consider AL-80B same basic circuit and can be purchased for less w/ warranty.
    First if purchased to build, would be to throughout all the caps and diodes in power supply buy new. That cost is close to $200 for those parts and upgrade boards.
    Some of these guys are delusional what they think that stuff is worth!

    543_Dallas likes this.
  6. BJ radionut

    BJ radionut Supporting Member and 6m addict

    Joined:
    May 9, 2008
    Messages:
    2,450
    Likes Received:
    1,871
    Another issue is the EIMAC 3-500z tube. Some of the last several batches of Eimac's that were produced around that time had the potential to be "gassy" right out of the box.
    Some of those Heathkit amps at that time had those tubes.
    Eimac soon after the huge batch of warranty claims, cease to produce 3-500z tubes.
    (late 80's early 90's I think ?)
    So potential to build that kit could lead to even more expensive cost if the tube were bad also.
    The SB-1000 amps also had cooling issues. (not enough airflow to the base of the tube).
    This caused the solder on the filament pins to run hot and actually melt the solder out the bottom of the pins.
    This issue normally occurred when the amp was operated near full output for a long duration, or in AM service above rated duty cycle. ( @ 900-1000 watts PEP output)
    The SB-1000 /AL-80 A (B) are GOOD amps but reality shows they are best operated around 700 watts PEP output.
    All the Best
    Gary

  7. Mudfoot

    Mudfoot Sr. Member

    Joined:
    Jun 17, 2009
    Messages:
    9,442
    Likes Received:
    4,025
  8. nomadradio

    nomadradio Analog Retentive

    Joined:
    Apr 3, 2005
    Messages:
    3,038
    Likes Received:
    2,976
    Makes me wonder if the always-suicidal power transformer has good miles on it yet, or if age alone is what makes them go bad. Would love to hear how long the transformer lasted after this thing gets built and put into harness.

    I have one of these that we rebuilt with a new Ameritron AL80B transformer. And another one with the original in it. I'm hesitant to sell the thing. Murphy's Law says the transformer will flame out before the buyer has it for a week.

    Just don't need the aggravation.

    73

  9. Tallman

    Tallman W9WDX Amateur Radio Member, KW4YJ EXTRA class

    Joined:
    May 1, 2013
    Messages:
    4,316
    Likes Received:
    4,047
    Chevboy0167 likes this.
