Gamma Matches

Discussion in 'Home Brew' started by TheRealPorkchop, Apr 25, 2021.

  1. TheRealPorkchop

    TheRealPorkchop Certified Sith Pimp

    Joined:
    Aug 25, 2015
    Messages:
    2,802
    Likes Received:
    4,201
    Where’s a good source of information to properly build a high wattage gamma?

    More specifically, the in’s & out’s of which material to chose and why, how to build one that will handle higher power input. I’m aware I could buy one but what fun is that?

    I’d like to build one that’ll handle at the very least 5kw.



    Which brings the question to the table, the ratings offered by Maco, is that PEP figures or CW/AVG?


  2. groundwire

    groundwire Sr. Member

    Joined:
    Jul 19, 2014
    Messages:
    719
    Likes Received:
    980
    Arrl handbook

    TheRealPorkchop likes this.
  3. snow bird

    snow bird Well-Known Member

    Joined:
    Sep 28, 2017
    Messages:
    247
    Likes Received:
    324
    Chop Hi You can use Copper or S S or brass Even Alu Use thick wall tubing and good Surgital tubing For your Ins

    TheRealPorkchop likes this.
  4. TheRealPorkchop

    TheRealPorkchop Certified Sith Pimp

    Joined:
    Aug 25, 2015
    Messages:
    2,802
    Likes Received:
    4,201
    I knew the ARRL was a great place to start but Snow Bird has hit the nail on the head. That’s more of what I’m thinking about.

    I want a near blow-proof gamma on my beams. I’m giving serious consideration to stacking my pair of shooting stars, absolute ridiculous overkill. And I don’t want to have to take them down over a crappy built gamma.

    Shadetree Mechanic and S&W357 like this.
  5. BJ radionut

    BJ radionut Supporting Member and 6m addict

    Joined:
    May 9, 2008
    Messages:
    3,652
    Likes Received:
    3,955
    Try one of Bill Orr's Radio Eng handbooks...many editions on-line...I think there are link's here to find several edition(versions)...
    As far a insulators for the adjustment tubes...Teflon or Delrin comes to mind as holding up to the power.
    All the Best
    Gary

  6. TheRealPorkchop

    TheRealPorkchop Certified Sith Pimp

    Joined:
    Aug 25, 2015
    Messages:
    2,802
    Likes Received:
    4,201
    I like the Delrin. Thanks BJ.

  7. Shockwave

    Shockwave Sr. Member

    Joined:
    Sep 19, 2009
    Messages:
    3,736
    Likes Received:
    3,115
    Derlin may be easier to find and less expensive than Teflon. However, make no mistake because Teflon is the superior material to use in a high power gamma match. Teflon can handle twice the heat without melting and is also not prone to cracking over time. Because of the difficulty finding Teflon in the right diameters, this is an item I suggest most people buy if you can't find a good source for the insulator.

    With respect to the Maco gamma match ratings, they must have been PEP because the early 10KW model use to fail regularly as soon as you past 7,500 average on the Bird. I believe Tom has upgraded the Maco gamma match as he mentioned this last time I spoke to him. The real bullet proof replacement for a gamma match is a ceramic vacuum variable capacitor.

    #7 Shockwave, Apr 28, 2021
    Last edited: Apr 28, 2021
    Shadetree Mechanic and bob85 like this.
  8. TheRealPorkchop

    TheRealPorkchop Certified Sith Pimp

    Joined:
    Aug 25, 2015
    Messages:
    2,802
    Likes Received:
    4,201
    I contacted Maco and they said the 2kw factory piece was rated as average power or continuous.

    I’m having a hard time believing that, that’s why I’m looking for an alternative and I want to build it. Most likely I won’t be exceeding 4kw PEP. The tower will tilt but ain’t nobody got time for that.

  9. Shockwave

    Shockwave Sr. Member

    Joined:
    Sep 19, 2009
    Messages:
    3,736
    Likes Received:
    3,115
    You should beware that the stock UHF connectors are the weakest link on these antennas and usually short out long before the stock gamma. The stock gamma can handle 2kw continuous but, that doesn't mean it can handle more peak. The issue here is the breakdown voltage and you only have to reach it for a fraction of a second for an arc to punch through the insulator.

    Replace both UHF connectors with Teflon insulated SO-239's. Solder an eye connector to the back of the SO-239's, so you can use a screw, washer and nut to attach a Maco 5kw Teflon insulated gamma match. Use GE clear silicon II, to seal the back side of the connector. This will meet your requirements.

  10. HomerBB

    HomerBB Sr. Member

    Joined:
    Jan 4, 2009
    Messages:
    3,781
    Likes Received:
    2,168
    I've used PEX tubing for gamma insulators, but have never run high power. What say you guys..?

    Shadetree Mechanic likes this.
  11. TheRealPorkchop

    TheRealPorkchop Certified Sith Pimp

    Joined:
    Aug 25, 2015
    Messages:
    2,802
    Likes Received:
    4,201
    So buy their 5kw gamma and mod it with Teflon, is that what you’re saying?

  12. Shockwave

    Shockwave Sr. Member

    Joined:
    Sep 19, 2009
    Messages:
    3,736
    Likes Received:
    3,115
    The 5kw was Teflon last time I used one. So is the 10kw and Tom told me they have one even bigger now. Perhaps a 40?

    The weak link is the stock antenna connectors with the stud that bolts to to gamma match. Inside the stock UHF connector there is an insulator and the gapping used here is the limiting factor. Replace those with quality Teflon insulated SO-230 connectors. The 10 kw model is supplied with a porcelain stand off insulator with a bolt that connects to "pigtails" on the cable, rather than a PL-259.

    #12 Shockwave, Apr 29, 2021
    Last edited: Apr 29, 2021
    TheRealPorkchop likes this.
  13. Shockwave

    Shockwave Sr. Member

    Joined:
    Sep 19, 2009
    Messages:
    3,736
    Likes Received:
    3,115
    PEX breaks down when exposed to sunlight (UV) and has a low melting temperature. You also have to watch out for any color additive (black can be a problem) that may be conductive at RF. Test a piece you use in the microwave. If it does not melt or burn up, you know it has no conductive properties.

    If you cover any exposed PEX with heat shrink tubing and run conservative power (it de-rates as frequency increases), you will probably not have any issue. How much it heats in the microwave will give an indication of its RF losses. Just because it gets warm at microwave frequencies, does not mean it will be useless at HF either.

    TheRealPorkchop and HomerBB like this.
  14. TheRealPorkchop

    TheRealPorkchop Certified Sith Pimp

    Joined:
    Aug 25, 2015
    Messages:
    2,802
    Likes Received:
    4,201
    My idea of bright and shiny, you just knocked it right out of me. This is a better idea I gues and faster. Maybe I need to just pony up and get the 10kw version and be done with it.
