My little radio and semi-pro audio shack

Discussion in 'Station & Mobile Pics' started by fourstringburn, Jan 9, 2015.

  1. fourstringburn

    fourstringburn W9WDX Amateur Radio Club Member K5KNM

    Joined:
    Feb 11, 2007
    Messages:
    1,704
    Likes Received:
    1,067
    [​IMG]

    Large format mixer and studio monitors are for my home studio recording audio gear, I do use a small format Yamaha MG-10 mixer (not visible) to interface boom mounted mic to HF radios
    .



    [​IMG]



    [​IMG]



    [​IMG]

    #1 fourstringburn, Jan 9, 2015
    Last edited: Jan 9, 2015

  2. w9cll

    w9cll W9WDX Amateur Radio Club Member

    Joined:
    Jan 19, 2013
    Messages:
    3,211
    Likes Received:
    1,819
    Looks nice and professional but why?

  3. fourstringburn

    fourstringburn W9WDX Amateur Radio Club Member K5KNM

    Joined:
    Feb 11, 2007
    Messages:
    1,704
    Likes Received:
    1,067
    Thanks, and why not?

    The audio gear is for my musical enjoyment recording demos for myself and other people.

    The pics may be misleading. I don't interface my audio gear with my HF rig.

    The ribbon mic on the boom would be the exception since I use it for both.

    Thanks for looking.

  4. w9cll

    w9cll W9WDX Amateur Radio Club Member

    Joined:
    Jan 19, 2013
    Messages:
    3,211
    Likes Received:
    1,819
    You are right the pics were misleading, nice setup

  5. jeffbones

    jeffbones New Member

    Joined:
    Jun 21, 2015
    Messages:
    6
    Likes Received:
    0
    very tidy. what padding are you using on the walls?

  6. fourstringburn

    fourstringburn W9WDX Amateur Radio Club Member K5KNM

    Joined:
    Feb 11, 2007
    Messages:
    1,704
    Likes Received:
    1,067
    Thanks for looking!

    All that padding is foam padding used to put on top of bed mattresses to provide more cushion.

    I found that years ago at Walmart I believe, and works well for a cheap way to provide sound dampening and has that old egg crate appearence, and is hung with thumbtacks into the wall.

  7. rabbiporkchop

    rabbiporkchop Well-Known Member

    Joined:
    Jan 18, 2007
    Messages:
    1,560
    Likes Received:
    422
    What kind of ribbon microphone is that?

  8. fourstringburn

    fourstringburn W9WDX Amateur Radio Club Member K5KNM

    Joined:
    Feb 11, 2007
    Messages:
    1,704
    Likes Received:
    1,067
    Thanks for looking , that's the AEA R84 ribbon mic.

    Expensive but worth it for clear, uncolored SSB audio. Ribbon mics go back a long time and were widely used during the golden age of broadcast radio.

    They are still highly regarded today but there use is usually limited to studio recording due to their fragile nature.

    Pic below is a newscaster with a now highly prized RCA 44 ribbon mic.
    [​IMG]

    Steve_Buckeye likes this.
  9. rabbiporkchop

    rabbiporkchop Well-Known Member

    Joined:
    Jan 18, 2007
    Messages:
    1,560
    Likes Received:
    422
    I wonder how it would compare to an electro-voice re 20 with the RE20 at half the price?

    #9 rabbiporkchop, Jan 28, 2016
    Last edited: Jan 28, 2016
  10. fourstringburn

    fourstringburn W9WDX Amateur Radio Club Member K5KNM

    Joined:
    Feb 11, 2007
    Messages:
    1,704
    Likes Received:
    1,067
    It's a question of personal tastes and what you're looking for in your transmit audio, and more importantly if is being used on a CB or HF radio.

    The RE-20 is a very fine mic and many people use them on SSB with excellent results. The Shure SM7B and the affordable Shure SM58 are widely used too and are worth looking into as well. They are all dynamic mics and have their own sound even before any processing is used. This isn't a bad thing by the way.

    Ribbon mics that are designed like the vintage mics of yesteryear is about as pure and uncolored voice quality as you're going to get with a full range flat frequency responce of 20 Hz to 20 KHz. Many other mics like the RE20 frequency response curve is 45 Hz to 18 KHz.

    rabbiporkchop likes this.
  11. 222DBFL

    222DBFL Sr. Member

    Joined:
    Jul 28, 2013
    Messages:
    3,301
    Likes Received:
    1,290
    Very nice setup fourstringburn! What you say you do again?? What band you travel with??;):D. Or you play yourself?? At any rate, sweet little studio you have there!!!

  12. Captain Kilowatt

    Captain Kilowatt Professional Amateur
    Staff Member

    Joined:
    Apr 6, 2005
    Messages:
    14,947
    Likes Received:
    6,491
    In my opinion the RE20 is over rated however it is a very good microphone. We used them in our main broadcast studios but replaced them with Sennheiser MD-421's. The difference was quite noticeable. The MD-421 has a much higher output level, better ability to handle really loud volumes, a bit better bass response and better overall audio presence. It also picks up less background noise off-axis than the RE20. It also has a rotary five position switch mounted on the rear by the connector which is a roll-off filter which greatly changes the sound. I use one on my Heath amateur radio AM station and it sounds superb. Don't get me wrong, the RE20 is a good mic and you will see a lot of them in use at home studios and amateur radio stations operated by professional audio or broadcast techs but I often wonder if the reason is because they were obtained quite cheaply or even free when they were replaced.

    As for that RCA44 pictured above, I have an RCA ribbon mic that looks like that one but just not sure the model number. I forget since it has been so long. I must dig it out and check it out sometime. Got a couple old Shure "salt and pepper" mics too. Again the model number eludes me at the moment.

    rabbiporkchop likes this.
  13. fourstringburn

    fourstringburn W9WDX Amateur Radio Club Member K5KNM

    Joined:
    Feb 11, 2007
    Messages:
    1,704
    Likes Received:
    1,067
    I play with myself! LOL.

    Thanks for looking and thanks for the compliment. I don't really play with any bands right now but I still enjoy playing music as a classically trained pianist and hard rock/metal bass player. Hence the moniker, Fourstringburn.

    Riverman71 likes this.
  14. fourstringburn

    fourstringburn W9WDX Amateur Radio Club Member K5KNM

    Joined:
    Feb 11, 2007
    Messages:
    1,704
    Likes Received:
    1,067
    Have you come across this mic in your field? If so, any feedback?


    [​IMG]
    This is the Neuman BCM-705 dynamic broadcaster series mic. This is a first for Neuman since all their mics are condenser. This mic does come in a more expensive condenser series also ( BCM-104 ).

    rabbiporkchop likes this.
  15. 222DBFL

    222DBFL Sr. Member

    Joined:
    Jul 28, 2013
    Messages:
    3,301
    Likes Received:
    1,290
    No I get it totally. And I get the being hard core for sure!! Like I said, nice little studio ya got there man. I'm sure you can rock out in there and sound great as well. Been a while since I have seen that much stuff. One of my ex girlfriend's Dad was a musician and sang at weddings and events and such. Big Italian dude. At any rate. As long as you are having a good time, then it's all worth the effort to make it as neat as you have it. Job well done!!
