Antenna choices and opinions.

Discussion in 'Amateur Radio Antennas' started by Low_Boy, Dec 7, 2018.

  1. Low_Boy

    Low_Boy Well-Known Member

    Joined:
    Jan 21, 2010
    Messages:
    734
    Likes Received:
    215
    I think my trusty A99 has finally had it and it is time to be replaced after about 7 or 8 Yrs. It has worked good and I am able to use it on 10,11 12, 15 and even 20 Mtr.used with a tuner on all bands but 11Mtr. I am wondering what would be another option. I like the Super Penetrator but it is strictly 10 and 11 Mtr. which is not that much of a problem. I also like the Imax 2000. The pluses of that is is it is more broad banded and easier to install in the winter. Any other thoughts would be appreciated.
    Thanks.




  2. TheRealPorkchop

    TheRealPorkchop Certified Sith Pimp

    Joined:
    Aug 25, 2015
    Messages:
    1,136
    Likes Received:
    1,033
    Everybody always screams Imax when I pose that question... I’d prefer a tower and a beam but I don’t really need it. Not now anyway.

  3. Tallman

    Tallman W9WDX Amateur Radio Member, KW4YJ EXTRA class

    Joined:
    May 1, 2013
    Messages:
    3,020
    Likes Received:
    2,085
    You don't even need the radio either, I have seen a video where you choke out a dissenting voice in the room without touching him.
    [​IMG]

    Low_Boy likes this.
  4. TheRealPorkchop

    TheRealPorkchop Certified Sith Pimp

    Joined:
    Aug 25, 2015
    Messages:
    1,136
    Likes Received:
    1,033
    That’s true. I don’t know why I even own the antenna, it won’t reach my Death Star because of the power line noise issue I have.

    Freaking Ewoks stole all my speeder bikes.

    This butthole in a wore out spaceship with a wannabe Sasquatch keeps blowing up all my tie-fighters.

    It’s not easy being a Sith Pimp.

    Maybe I should try the Imax, retire the Magnum S9 and break out the Yaesu?

  5. Low_Boy

    Low_Boy Well-Known Member

    Joined:
    Jan 21, 2010
    Messages:
    734
    Likes Received:
    215
    10-4 That really was a derailment.

  6. Handy Andy

    Handy Andy Do Your Research First, Then Decide...

    Joined:
    Apr 23, 2018
    Messages:
    1,580
    Likes Received:
    1,299
    [​IMG]

  7. 543_Dallas

    543_Dallas Sr. Member

    Joined:
    Jul 25, 2011
    Messages:
    1,711
    Likes Received:
    1,728
    If it were for 10, 11 and 12 meters I would go with something like the penetrator. Since You're going all the way to 20 meters I would get another a99 or imax. A tuner will allow you to use the penetrator on on the same bands but since it is narrow banded the swr at the feedpoint will be much higher. The higher the swr is on the coax is the more loss it will have. I would use rg213 or better coax to keep the loss as low as possible. If at all possible consider moving the tuner closer to the antenna. Keeping the coax between the tuner and antenna as short as possible helps.

  8. BJ radionut

    BJ radionut Supporting Member and 6m addict

    Joined:
    May 9, 2008
    Messages:
    1,820
    Likes Received:
    980
    http://www.hy-gain.com/Product.php?productid=AV-14AVQ
    This or one of the other models available may give you better performance, as they are actually tuned for those bands.
    A few radials can make these work fairly well. See the PDF info for options when mast mounting. I had the 10/15/20m version mounted at like 25 ft. Worked very well with 4 radials per-band. I used old style 4 conductor flat rotor cable, then cut each of the 4 wires to length one for each of the bands using the flat cable....Just something to think about. That may prove to give you better performance.
    All the Best
    Gary

    543_Dallas and sp5it like this.
  9. Blackcat630

    Blackcat630 Sr. Member

    Joined:
    Apr 2, 2013
    Messages:
    477
    Likes Received:
    346
    Kinda depends on what you want to do with it. If broadbandedness is of major importance the Imax might be your best bet. Unfortunately I have heard reports of the QC slipping with solarcon lately. The last one I had I bought probably 6 yrs ago. It worked just fine until lightning took it out this past August. Worked 15-10 without a tuner. Surprisingly 15 meters had very low swr throughout the majority of the band and made a few contacts on 15 with it. Of course my dummy load has a great swr throughout all the bands too.... Efficiency of the Imax might leave a lot to be desired...especially the further you get away from 10/11m. If 10-11m is your main focus there are better verticals on the market..

  10. sp5it

    sp5it Master of puppets

    Joined:
    Jul 9, 2009
    Messages:
    971
    Likes Received:
    498
    Nah, dummy load will be best choice in that case.
    Resonant antenna is the way to go. No antenna tuner or other crap.
    Mike

  11. Tallman

    Tallman W9WDX Amateur Radio Member, KW4YJ EXTRA class

    Joined:
    May 1, 2013
    Messages:
    3,020
    Likes Received:
    2,085
    I know that guy he calls his ship "The Aluminum Falcon" and the Sasquatch wannabe is the cookie monster from some street some where.


    #11 Tallman, Dec 7, 2018
    Last edited: Dec 7, 2018
    TheRealPorkchop likes this.
  12. Low_Boy

    Low_Boy Well-Known Member

    Joined:
    Jan 21, 2010
    Messages:
    734
    Likes Received:
    215
    Maybe I am asking for too much in a antenna.

  13. TheRealPorkchop

    TheRealPorkchop Certified Sith Pimp

    Joined:
    Aug 25, 2015
    Messages:
    1,136
    Likes Received:
    1,033
    Why not just get another A99 if it’s been working for you, until you can figure out exactly what you want/need?

    I want a tower and a beam but what I actually need in either one, I have no clue. I actually stay too busy to get much talk time in.

    I think the biggest problem is there’s too dang many choices for antennas.

  14. Tallman

    Tallman W9WDX Amateur Radio Member, KW4YJ EXTRA class

    Joined:
    May 1, 2013
    Messages:
    3,020
    Likes Received:
    2,085
  15. Low_Boy

    Low_Boy Well-Known Member

    Joined:
    Jan 21, 2010
    Messages:
    734
    Likes Received:
    215
    I would love a tower but that may have to wait until I retire.
