Galaxy DX 94

[bluelight1977]

I found this:
http://www.gijoesradioelectronics.com/scripts/prodView.asp?idproduct=1266
It´s a new radio replacing the old dx99v.
Does anybody have more information?
chris



[AudioShockwav]

DX 94-HP
From GTRS.

The radio will have one IRF520 mosfet driver and one IRF520 mosfet final driving four IRF520 transistors.
100 watts @ 25 amps.

Has a Auto-SWR Meter, Variable Talkback Control, Blue Channel and Frequency Display LEDs.
Blue S-Meter Display, StarLite faceplate for night driving and a New Generation main board for better frequency stability.
There are Pics on the CBTricks forum, and Bennie should have the info on it up soon.

73
Jeff



[AudioShockwav]

sneak peek.

73
Jeff



[HootyAl]

You got that one right Karo!!! As most of the other exports are made by or have ranger"s help. Wonder how many (mosfets)they can squeeze into one and still look like a mobile? :?:



[dudmuck]

You got that one right Karo!!! As most of the other exports are made by or have ranger"s help. Wonder how many (mosfets)they can squeeze into one and still look like a mobile? :?:

I don't know if you've seen the 98VHP on cbtricks..

Probably the same radio, just a different amplifier board attached.
On both radios, the frequency counter is only five digits, which is a bit limited for SSB use.

As a side curiosity, i am not sure what the motivation is to use the IRF520 mosfet instead of RF traditional transistors. The IRF520 isn't even intended as an RF amplifier, but its gate capacitance is low enough to perform ok at 27MHz.



[Crusher]

Like most things, they probably got a good price on the mosfets



[AudioShockwav]

Bennie Has the service info up on the Radio at CBTricks.com
Includes a picture tour of the radio.

www.cbtricks.com/radios/galaxy/dx94hp/index.htm


73
Jeff



[bluesman92961]

will you be able to run a 2 pill or a 4 pill amp with this radio
